INFORMATION SHEET

CORNER MULTI FUEL STOVE



22-05-15





SILENT SIMPLICITY JUST FOR YOU

Introduced to the marine market some 15 years ago and rapidly seized upon up by the best boat builders, the advanced features of the triangular solid fuel corner stove have made it into a huge success with both interior designers and boat owners alike.



Main Features

Seamless integration with internal layouts.

Triangular profile and built in heat shields allow the stove to be integrated seamlessly with interior layouts creating a fully fitted and not just stuck there look.



Multi Function

It can burn wood, peat or solid fuel and cook on the top plate.

Heat your boat with a dry version or centrally heat and produce hot water with a wet version; it’s the only stove with an optional fully integral, wrap round boiler..



Ash Cleanliness

The special internal design of the combustion chamber and front fret constrains ash where it should be, inside the stove and not on the hearth in front of it. In addition the stove has a deep ashpan capable of holding 24 hrs continuous burning.





All Night Burning

The best shaped firebed for solid fuel burning is round; the next best shape is triangular

The fire grate is set deep down below the solid front fret allowing for good quantities of fuel to be loaded making all night burning an easy prospect.



Clean Burning

Three controlled air routes into the stove.

Air wash air to help keep the door glass clean.

Over fire air for wood burning.

Under fire air for solid fuel.

Additional Features

Fully adjustable door hinges.

Fully adjustable door lock.

Stay cool easy to use door handle.

Stainless steel grate.

Stainless steel grate carrier.

Stainless steel front fret.

Stainless steel baffle plate

Cook top with fiddle rail.



About the Stove

For fellow enthusiasts of Sustainable Living, the Corner Solid Fuel Stove is designed to generate and maintain high combustion chamber temperatures and is both clean and easy to use.

High temperature combustion ensures that most of the fuel is burnt so reducing smoke, tar and particulate emissions which are currently causing concern with air pollution.

High temperature combustion is achieved by the careful use of high performance firebrick linings which fit on the inside of the firebox and front fret designed to allow the combustion chamber to achieve and maintain a high operating temperature as quickly as possible.

The Corner Solid Fuel Stove incorporates three separate air inlet controls:-

An Air Wash System operated by a simple lever control.

A Secondary Overfire Air System for wood burning and a Primary Underfire Air Control System for burning smokeless fuel both of which are operated by a simple rotary valve.

All of these controls provide the user with the necessary tools to achieve a steady, high degree of temperature control.

Ash spillage, leakage and resultant mess is a major problem on boats and as a consequence we have designed features into the stove to mitigate this problem.

Bubble Stoves can significantly reduce your running costs and produce the most amazing pyrotechnics which demonstrate our technology at work.

Fall in love with a Pie Pod and it will give you many hours of fun and pleasure.

GREEN ENERGY when wood burning.











WEIGHT.

Dry Stove  60kg

Wet Stove  70kg

Designed and manufactured in the U.K.
